| Mode | JC2016 | |
| Print Head | 16 pcs Epson i3200 print head | |
| Print Resolution/Speed | Produce Mode:560㎡/H | |
| Resolution Mode:280㎡/H | ||
| High Resolution Mode:140㎡/H | ||
| Maximum Print Width | 1900mm | |
| Ink type | Sublimation lnk | |
| Media | Width | 1900mm |
| Thickness | 1.5mm to 8mm adjustable for print head | |
| Weight | 560KG | |
| Type | Heat transfer paper | |
| High Printing Quality | VSD technology | |
| Media Heat method | Pre /Back Heater (can be controlled separately)（Optional） | |
| Media feeding Device | 10,000 meters | |
| Drying System | External air drying system | |
| Guide Rail | THK From Japan | |
| Interface | Three Gigabit network cards, 1000Mbit/s | |
| RIP Software | Maintop V6.0, Photo-print | |
| Voltage | AC 110V ± 10 %、AC 220 V ± 10 %、50 / 60 ± 1Hz | |
| Operation Environments | Temperature: 15℃-30℃, Humidity: 35%RH-65%RH | |
| Power | 16500W | |
| Dimensions of Printer(L*W*H) | 3701*2826*1701mm | |
| Packing dimensions: | Main body (LWH): | 3.94*1.55*1.88M |
| Media feeding system (LWH): | 2.945*1.11*1.25M | |
| Net Weight | 800+400（KG) | |
| Weight | 950+550(KG) | |
