PARAMETER
| Model | JC0705 | ||
| Print head | 5 pcs i3200 print heads | ||
| Print resolution /Speed | Product mode | 36㎡/H | |
| Resolution mode | 30㎡/H | ||
| High resolution mode | 26㎡/H | ||
| Ink | Ink sort | DTF pigment ink | |
| Ink supply mode | Empty ink supply system | ||
| Media | Width | 600mm | |
| Thickness | 1.5-8mm | ||
| Max weight | 75KG | ||
| Sort | Hot painting materials，Clothing hot painting，offset printing material，Engrained film，canvas bag，hat. | ||
| High resolution | VSD technology | ||
| Media heater | Front/back heating (can be controlled separately) | ||
| Take-up system | Simple take-up system | Heavy take-up system | |
| Guide Rail | THK from Japan | ||
| Interface | 1000Mbit/s | ||
| RIP software | Maintop | ||
| Voltage | AC 220V± 10%,50/60 ±1Hz | ||
| Operation environments | Temperature: 15℃-30℃,Humidity:35%RH-65%RH | ||
| Printer power | 2500W | ||
| Oven Power | 6000W | ||
| Dimensions of printer (LWH) | Printer:1933*850*1600mm;Oven:2700*990*1000mm | ||
| Dimensions of packing (LWH) | Printer:2090*830*820mm; Oven:2280*1140*1160mm | ||
| Net weight | Printer:150KG;Oven:272KG | ||
| Gross weight | Printer:220KG;Oven:360KG | ||
